DQ Series Relay/Control

The DQ Series Relay/Control provides precise control for consistent plating and etch rates in most aqueous processes. It features a large, easy-to-read (.56” high) LED display and two set points for heating and cooling. Included is a 10-foot (3m) fluoropolymer (FEP) covered, 1000-ohm platinum RTD sensor. The unit is vapor-resistant with a NEMA 1, IP21, gasketed 1/4 DIN plastic enclosure and sealed tactile switches with stainless steel hardware. It supports up to 30 amps at 120-240 volts and operates in either single or three-phase configurations. The adjustable temperature range extends from -40°F (-40°C) to 1000°F (538°C).
